TV Power Products

The backlight system is composed of light-emitting components, light guide plates and backlight power supplies. TV backlight power supplies generally have a power rating of 100 to 500 watts. They mainly convert mains AC voltage into 12V DC to power the display. The display’s mainboard is equipped with DC-DC converters to generate 8V, 5V, 3.3V and 2.5V voltages, so the 12V DC output fully meets the operating requirements of the display.

TV power supplies commonly adopt topologies including PFC, LLC, SR, Flyback and BOOST+CC/CV. Inmark supplies high-voltage and low-voltage MOSFETs featuring outstanding EMI performance and superior heat dissipation, enabling backlight power supplies to achieve miniaturization and slimmer design.
