MOT80N06A
Suitable for load switching, PWM control, BMS, motor drives and efficient DC power management.
Product information
Specifications, documents and sourcing support for MOT80N06A.
Technical specifications
Parametric data for product selection and design review.
- Cargo Status
- Active
- Supplier Device Package
- TO-220
- BVDSS
- 60
- ID[A](25℃)
- 80
- VGS(th)[V](max)
- 4
- Rds(on) [ mohm] at Vgs=10V（TYP)
- 7
- Rds(on) [ mohm] at Vgs=10V（MAX)
- 9
MOT80N06A
Review electrical characteristics, package drawings and test conditions.
Overview & applications
Product positioning and recommended use cases.
MOSFET N 80V 60A 7 TO-220
MOT80N06A is an N-channel trench MOSFET in TO-220, rated at 60 V and 80 A. Low on-resistance and gate charge support efficient switching in motor-control, battery and power-management circuits.
Cross reference
Common market parts that may be evaluated against this MOT device.
| Manufacturer | Market part number | MOT part number |
|---|---|---|
| onsemi（原Fairchild） | FQP60N06L | MOT80N06A |
| STMicroelectronics | STP60NF06 | MOT80N06A |
| Vishay（原IR） | IRF2807 | MOT80N06A |
| Toshiba | TK30E08D | MOT80N06A |
| 扬杰科技（YJ） | YJM80N06A | MOT80N06A |
| 华润微（CRMC） | CRMC80N06A | MOT80N06A |
Cross references are a starting point for evaluation. Confirm electrical and package compatibility in the datasheets before design-in.
Talk to an application engineer
Send us your target specifications, quantity and application. Our engineering team will follow up through the Contact Us page.
