B0520WS
It is widely used in application fields such as point-of-sale machines, audio equipment, wireless transmission equipment, etc.
Product information
Specifications, documents and sourcing support for B0520WS.
Technical specifications
Parametric data for product selection and design review.
- Cargo Status
- Active
- Supplier Device Package
- SOD-323
- IO(A)
- 0.5
- VRRM(V)
- 20
- IFSM(A)
- 22
- VF(V)
- 0.39
- @IF(A)
- 0.5
- IR<(uA)
- 250
- @VR(V)
- 20
Overview & applications
Product positioning and recommended use cases.
DIODE 20V 0.5A 0.39V 250uA
B0520WS is a small signal Schottky diode with features of rectification circuit, switching power supply, protection circuit, etc.
Cross reference
Common market parts that may be evaluated against this MOT device.
| Manufacturer | Market part number | MOT part number |
|---|---|---|
| Diodes Inc. | B0520WS-7-F | B0520WS |
| Taiwan Semiconductor | B0520WS | B0520WS |
| Micro Commercial Components | B0520WS | B0520WS |
| Nexperia | PMEG2005AEP | B0520WS |
| 扬杰科技（YJ） | SS0520W | B0520WS |
| 长电科技（JCET） | B0520WS | B0520WS |
| 华润微（CRMC） | B0520WS | B0520WS |
| ROHM | RB520S-20 | B0520WS |
Cross references are a starting point for evaluation. Confirm electrical and package compatibility in the datasheets before design-in.
